Automatic Transformer Test System Oil Break Down Tester

General Information:

Keywords: Oil Dielectric Strength Tester
Oil Breakdown Tester
Transformer Oil Dielectric Strength Tester

SXOT-II conforms to international standard IEC-156 and national standard GB507-86, can be used for power frequency dielectric break down test on the transformer oil, capacitor oil, electric device, insulation tool, electric manufacturer and etc. It's widely used in the fields of power system, petroleum, chemical industry, railway station, power station, electric manufacturer and etc.

Features:
√ Self detecting function. The regulator could return to zero start automatically.
√ Controlled by micro computer, easy to operate.
√ Build-in printer.
√ Automatic magnetic bar stir, to eliminate uneven and bubble of oil.
√ The user could select the test times, static stirring time, sound/light alarm continuously printing or stop printing.

The equipment to match the standard IEC 156, and the instrument is fully automatic type.

Specification:

Power supply: AC 200V-240V ,50HZ ±5%Test voltage: : AC 0~100KVLimitation current: 5mATest precision: 1%Voltage boosting rate: 2KV/s±10%Presetting: 1-9 times Stirring time: 0-1 minute 9 seconds
Static time: 0-10 minutes 39 secondsEnvironmental temperature: 0-35ºCRelative humidity: ≤75%RHPower: 300VAElectrodes Gap Size: 2.5mmVolume: 420×320×325mmWeight: 28KGWarranty: One year quality guarantee after shipment.


More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
